                  SIEMENS SOLID EDGE EXERCISES
Do you want to learn how to design 2D and 3D models in your favorite Computer Aided Design (CAD) software such as SOLID EDGECATIA, FUSION 360 or SolidWorks? Look no further. We have designed 200 CAD exercises that will help you to test your CAD skills.

What’s included in the SIEMENS SOLID EDGE EXERCISES book?

Whether you are a beginner, intermediate, or an expert, these CAD exercises will challenge you. The book contains 200 3D models and practice drawings or exercises.

  • Each exercise contains images of the final design and exact measurements needed to create the design.
  • Each exercise can be designed on any CAD software which you desire. It can be done with AutoCAD, SolidWorks, Fusion 360, DraftSight, PTC Creo NX, CATIA and other feature-based CAD modeling software.
  • It is intended to provide Drafters, Designers and Engineers with enough 3D CAD exercises for practice on SOLID EDGE.
  • It includes almost all types of exercises that are necessary to provide, clear, concise and systematic information required on industrial machine part drawings.
  • Third Angle Projection is intentionally used to familiarize Drafters, Designers and Engineers in Third Angle Projection to meet the expectation of worldwide Engineering drawing print.
  • This book is for Beginner, Intermediate and Advance CAD users.
  • Clear and well drafted drawing help easy understanding of the design.
  • These exercises are from Basics to Advance level.
  • Each exercises can be assigned and designed separately.
  • No Exercise is a prerequisite for another. All dimensions are in mm.

                                         Prerequisite
To design & develop models, you should have knowledge of SOLID EDGE. Student should have knowledge of Orthographic views and projections. Student should have basic knowledge of engineering drawings.

After purchasing, a download link will be sent to your Email instantly.

SIEMENS SOLID EDGE ASSEMBLY DRAWINGS

This book has been designed for self-paced learning by doing assembly practice exercises. This book doesn’t provide you with a step by step tutorial. This book is intended to provide cad assembly practice exercises.

What’s included in the SIEMENS SOLID EDGE ASSEMBLY DRAWINGS book?

Whether you are a beginner, intermediate, or an expert, these CAD Assembly exercises will challenge you. The book has various cad assembly exercises.

  • Each exercise contains images of the final Assembly design and exact measurements needed to create the design.
  • Each exercise can be designed on any CAD software which you desire. It can be done with AutoCAD, SolidWorks, Fusion 360, DraftSight, PTC Creo NX, CATIA and other feature-based CAD modeling software.
  • It is intended to provide Drafters, Designers and Engineers with enough CAD Assembly exercises for practice on any cad program.
  • It includes almost all types of exercises that are necessary to provide, clear, concise and systematic information required on industrial machine part drawings.
  • Third Angle Projection is intentionally used to familiarize Drafters, Designers and Engineers in Third Angle Projection to meet the expectation of worldwide Engineering drawing print.
  • This book is for Beginner, Intermediate and Advance CAD users.
  • Clear and well drafted drawing help easy understanding of the design.
  • These exercises are from Basics to Advance level.
  • Each exercises can be assigned and designed separately.
  • No Exercise is a prerequisite for another.
  • All dimensions are in mm.

                                                           Prerequisite

To design & develop models, you should have knowledge of SIEMENS SOLID EDGE program. Student should have knowledge of Orthographic views and projections. Student should have basic knowledge of engineering drawings.

After purchasing, a download link will be sent to your Email instantly.
